Rotary Seal Literature

get_adobe_reader Free Acrobat® Reader™ software is required to view the PDF brochures that are listed below.

Kalsi Seals Handbook

Kalsi Seals Handbook

This handbook includes rotary seal implementation and troubleshooting guidelines, with a special emphasis on oilfield sealing applications. It is based on the collective wisdom of our senior staff members, who have many decades of experience in solving various seal implementation challenges. It is a valuable design manual for existing customers, and for individuals who are interested in using our rotary seals.

Rotary Seal Literature

Enhanced Lubrication Seals

A seal that facilitates the use of thinner lubricants and higher pressures and speeds, at the expense of greater hydrodynamic leakage. Applicable to surface equipment such as rotating drilling heads/ bop’s and high pressure hydraulic swivels.

Axially Constrained Kalsi Seals

The axially constrained seal provides improved abrasion resistance in applications having little or no differential pressure. Available for radial gland depths of 0.250” and 0.309”. Widely used as an oilfield mud motor balancing piston seal.

Wide Footprint Kalsi Seals

Wide Footprint Kalsi Seals

The wide footprint seal is a new generation Kalsi Seal for retaining pressurized lubricants. Key enhancements include improved environmental exclusion, increased lip width and increased compression.

Kalsi Rotary Seal Brochure

Kalsi Rotary Seal Brochure

This four page brochure provides a brief overview of Kalsi Engineering and Kalsi rotary shaft seals, which are used in drilling mud motors, oilfield rotary steerable tools, high pressure coring swivels, and other abrasive service equipment.

High Temperature Kalsi Seals

High Temperature Kalsi Seals

A composite FKM/TFEP rotary seal construction for high temperature service in applications with low and medium pressure differential, such as the rotary steerable tools used in oil well drilling.

Cement Pump Seal Cartridge

Cement Pump Seal Cartridge

A pump seal cartridge that provides improved reliability and longer life in oilfield well cementing service. The rotary seals hydroplane on a film of oil to reduce seal-generated heat. A special purpose seal serves as a pump that flushes a pair of lip seals.

Hybrid Kalsi Seals

Hybrid Kalsi Seals

A seal that combines enhanced lubrication and zigzag waves to extend performance over more conventional seals. The Hybrid Seal be designed for performance ranging from that of the Wide Footprint Seal to the Enhanced Lubrication Seal.

Hydraulic Swivel Seals

Hydraulic Swivel Seals

This brochure outlines recommended practices for using Kalsi-brand swivel seals in multi-circuit high pressure hydraulic swivels.

Low Breakout Friction Seals

Low Breakout Friction Seals

An optional surface treatment reduces the breakout torque of HNBR seals. This treatment was developed for applications that are sensitive to breakout torque, such as underwater vehicles, oilfield rotary steerable tools, and rotary control devices.

Filled Kalsi Seals

Filled Kalsi Seals

A soft integral energizer significantly reduces seal-to-shaft contact pressure, breakout torque, and running torque.

Mining Seal Brochure

Mining Seal Brochure

Kalsi Seals are used in various severe service rock cutting applications, such as mining, coring, utility drilling, and well drilling. Seals with extra wide dynamic lips are now available to provide a significant increase in sacrificial material.

Technical Papers

OTC-26899-MS

OTC-26899-MS

This 2016 paper describes advancements in high pressure rotary sealing, including test results at a PV of 1.89 million.
Click here to order

SPE/IADC 37627

SPE/IADC 37627

This paper describes rotary seal innovations related to oilfield drilling and production equipment such as mud motors, rotary control devices, artificial lift pumps, rotary steerable tools, and high pressure swivels.
Click here to order

Literatura en Formato PDF de Sellos Rotatorios Kalsi

Folleto informativo sobre las juntas hermeticas Kalsi

Folleto informativo sobre las juntas hermeticas Kalsi

Este folleto presenta una visión general de los sellos Kalsi para ejes giratorio. Los sellos Kalsi se utilizan en motores de perforación, herramientas giratorias orientables, unión de articulación de alta presión y otros equipos en servicio abrasivos.

Juntas hermeticas Kalsi cuestionario

Juntas hermeticas Kalsi cuestionario

Utilize este impreso para solicitar asistencia en su aplicación.

Rotary Seal Literature in Russian

Other Kalsi Engineering Literature

Kalsi Engineering Brochure

Kalsi Engineering Brochure

This 16 page brochure describes the background, capabilities, products and services of Kalsi Engineering.

JarPro Jarring Analysis Software

JarPro Jarring Analysis Software

JarPro is a general-purpose drillstring jarring analysis software program. It facilitates the proper selection and placement of oilfield jarring tools.
