Enhanced Lubrication Kalsi Seal™ Sizes

Enhanced Lubrication (EL) Seals incorporate the most aggressive bi-directional hydrodynamic wave geometries that have been developed. They were initially created for use in high pressure rotary shaft seal applications such as oilfield rotating control devices (RCDs) and high pressure hydraulic swivels. Click here to read about a 5,000 psi, 40-day test.

The increased hydrodynamic lubrication of the dynamic surface significantly increases the pressure, speed, and abrasion resistance capability of these rotary seals. The increased lubrication also makes it possible to lubricate much wider dynamic lip widths, compared to Wide Footprint Seals™. The wider lip width of this high-pressure seal design further increases its ability to resist extrusion damage and abrasive wear, which are important attributes for an RCD seal. The tables below cover five different lip widths of enhanced lubrication seals™. Additional seal diameters can be furnished, subject to a one-time tooling charge to help defray associated engineering, machining, and setup expenses.

The wave geometry of this unique rotary shaft seal design can be customized to provide maximum performance for the allowable hydrodynamic pumping related seal leakage of the application. Four EL wave types have been developed ranging from moderate to maximum hydrodynamic lubrication. See handbook chapter C5 for additional information.

For optimum abrasion resistance, lubricant pressure or spring force is needed to provide the proper seal orientation in the gland.

Contact our engineering staff for assistance with implementing these unique high pressure oil seals in your rotary shaft seal assembly. Purchase orders and rotary seal quote requests should be sent to the attention of Seal Sales via e-mail, or by fax at 281-240-0255.

Standard Width Enhanced Lubrication Seals™

Basic Inside Diameter		Seal Part Number*	Seal Radial Depth D	Seal Axial Width (inches)	Gland Depth R (inches)**	Gland Width (inches) +0.005″ -0.000″**	Estimated As-Molded Diameter
							-10	-11	-106
0.375″	9.53 mm	568-201-*	0.197 ±0.003	0.170	0.177
0.492″	12.50 mm	568-196-*	0.266 ±0.003	0.170	0.246
0.550″	13.97 mm	568-180-*	0.202 ±0.003	0.170	0.182		0.550″/ 13.97 mm	0.550″/ 13.97 mm
0.984″	25.00 mm	568-192-*	0.247 ±0.003	0.180			0.984″/ 25.00 mm	0.984″/ 25.00 mm
1.500″	38.10 mm	568-133-*	0.335 ±0.005	0.250	0.309	0.310
1.969″	50.00 mm	568-146-*	0.335 ±0.005	0.250	0.309	0.310	1.967″/ 49.96 mm	1.969″/ 50.00 mm
2.000″	50.80 mm	568-137-*	0.335 ±0.005	0.250	0.309	0.310	1.994″/ 50.65 mm	1.996″/ 50.70 mm
2.750″	69.85 mm	568-24-*	0.335 ±0.005	0.250	0.309	0.310
2.750″	69.85 mm	568-39-*	0.335 ±0.005	0.250	0.309	0.310
2.750″	69.85 mm	568-43-*	0.335 ±0.005	0.250	0.309	0.310
4.330″	110.00 mm	568-198-*	0.335 ±0.005	0.250	0.309	0.310
5.000″	127.00 mm	568-139-*	0.445 ±0.005	0.300	0.419	0.355	5.020″/ 127.51 mm	5.025″/ 127.64 mm	5.000″/ 127.00 mm
9.012″	228.90 mm	568-190-*	0.329 ±0.005†	0.210†	0.303†	0.250†
9.765″	248.03 mm	568-114-*	0.450 ±0.006	0.300	0.424	0.355
10.945″	278.00 mm	568-121-*	0.450 ±0.006	0.300	0.424	0.355		10.945″/ 278.00 mm	10.945″/ 278.00 mm
13.000″	330.20 mm	568-131-*	0.415 ±0.005	0.300	0.389	0.355

Wide Footprint Enhanced Lubrication Seals™ (Lip is 1.5 times wider than standard width)

Nominal Inside Diameter for -10 and –11 HNBR Seals*		Seal Part Number*	Seal Radial Depth D	Seal Axial Width (inches)	Gland Depth R (inches)**	Gland Width (inches) +0.005″ -0.000″**
1.062″	26.97 mm	641-17-*	0.208 ±0.003	0.220	0.188	0.285
1.969″	50.00 mm	641-9-*	0.345 ±0.005	0.240	0.309	0.302
1.969″	50.00 mm	641-29-*	0.345 ±0.005	0.240	0.309	0.302
2.250″	57.15 mm	641-19-*	0.270 ±0.005	0.240	0.244	0.302
2.250″	57.15 mm	641-23-*	0.345 ±0.005	0.240	0.309	0.292
2.250″	57.15 mm	641-22-*	0.345 ±0.005	0.240	0.309	0.292
2.750″	69.85 mm	641-7-*	0.345 ±0.005	0.240	0.309	0.289
3.375″	85.73 mm	641-15-*	0.305 ±0.005	0.240	0.274	0.292
3.346″	85.00 mm	641-31-*	0.335 ±0.005	0.240	0.309	0.289
3.500″	88.90 mm	641-1-*	0.345 ±0.005	0.240	0.309	0.289
3.500″	88.90 mm	641-21-*	0.345 ±0.005	0.240	0.309	0.289
4.528″	115.00 mm	641-33-*	0.335 ±0.005	0.240	0.309	0.289
10.375″	363.53 mm	641-27-*	0.450 ±0.005	0.300	0.415	0.355

Wide Footprint Enhanced Lubrication Seals (Lip is 1.75 times wider than standard width)

Nominal Inside Diameter for -10 and -11 HNBR Seals*		Seal Part Number*	Seal Radial Depth D	Seal Axial Width (inches)	Gland Depth R (inches)**	Gland Width (inches) +0.005″ -0.000″**
2.750″	69.85 mm	660-1-*	0.345 ±0.005	0.240	0.309	0.289
4.803″	122.00 mm	660-6-*	0.345 ±0.005	0.240	0.309	0.289
5.000″	127.00 mm	660-4-*	0.345 ±0.005	0.240	0.309	0.289
5.079″	129.00 mm	660-8-*	0.345 ±0.005	0.240	0.309	0.289

Extra Wide Enhanced Lubrication Seals™ (Lip is 2.4 times wider than standard width)

Nominal Inside Diameter for -10 and -11 HNBR Seals*		Seal Part Number*	Former Part Number*	Seal Radial Depth D	Seal Axial Width (inches)	Gland Depth R (inches)**	Gland Width (inches) +0.005″ -0.000″**
2.750″	69.85 mm	655-4-*	568-79-*	0.335 ±0.005	0.335	0.309	0.400
2.750″	69.85 mm	655-7-*		0.335 ±0.005	0.335	0.309	0.400
2.750″	69.85 mm	655-29-*		0.335	0.270	0.309	0.335
2.750″	69.85 mm	655-37-*		0.345	0.300	0.309	0.375
3.250″	82.55 mm	655-30-*		0.335	0.270	0.309	0.335
4.500″	114.30 mm	655-10-*		0.415 ±0.005	0.335	0.389	0.400
4.500″	114.30 mm	655-33-*		0.415 ±0.005	0.300	0.389	0.375
4.500″	114.3 mm	655-35-*		0.415 ±0.005	0.300	0.389	0.375
5.000″	127.00 mm	655-6-*	568-141-*	0.445 ±0.005	0.335	0.419	0.400
5.500″	139.70 mm	655-40-*		0.415 ±0.005	0.300	0.389	0.375
8.268″	210.00 mm	655-5-*	568-135-*	0.415 ±0.005	0.335	0.389	0.400
8.434″	214.22 mm	655-1-*		0.261 ±0.005	0.300	0.235	0.365
8.434″	214.22 mm	655-3-*		0.415 ±0.005	0.300	0.389	0.375
8.875″	225.43 mm	655-43-*		0.415 ±0.005	0.300	0.389	0.375
10.649″	270.48 mm	655-21-*		0.260 ±0.005	0.300	0.235	0.365
10.900″	276.86 mm	655-15-*		0.415 ±0.005	0.300	0.389	0.375

Super Wide Enhanced Lubrication Seals™ (Lip is 4.5 times wider than standard width)

Nominal Inside Diameter for -10 and -11 HNBR Seals*		Seal Part Number*	Seal Radial Depth D	Seal Axial Width (inches)	Gland Depth R (inches)**	Gland Width (inches) +0.005″ -0.000″**
2.750″	69.85 mm	739-1-*	0.335 ±0.005	0.395	0.309	0.460
2.750″	69.85 mm	739-6-*	0.335 ±0.005	0.395	0.309	0.460
3.250″	82.55 mm	739-2-*	0.335 ±0.005	0.395	0.309	0.460

• To view the current rotary seal implementation guidelines (Kalsi Seals Handbook™), click here.

* The complete seal part number consists of the basic part number plus the material dash number. Actual diameter varies as a function of material selected. New tooling may be required for certain materials.
** For gland details, see Chapter D5 of the Kalsi Seals Handbook. Gland depth can sometimes be varied to achieve specific shaft sealing objectives; see handbook.
† Non-standard cross-sectional size, this is a rotary seal for oilfield rotary valve actuators with a 9″ shaft.

Updated: April 11, 2024

Kalsi-brand rotary shaft seals are offered for sale under the terms and conditions of the “Offer of Sale” that is included in the current revision of the Kalsi Seals Handbook.
